BJ194Z-9SY Automatic Three Phase Multifunction Electrical 3P4W Panel Meter For OEM

BJ-194Z Multi-Function Power Meter is a LCD screen electrical panel power meter. It is the ideal choice for monitoring and measuring of 3P4W or 3P3W power systems.

With optional expansion modules, it can also transmit the parameter into 2*Relay output (2DO) and 4*Switch input (4DI). For transformers, generators, capacitor banks and motors of the distributed detection, automatic control system, on-line monitoring display.

It can replace the traditional analog or many digital measurement instruments (such as ammeter, voltmeter, power meter, power factor meter, frequency meter, etc.) with the advantages of improving system reliability, making the on-site wiring convenient and reduce system cost.

It can measure all of the power parameters in power grid:
Current,
Voltage,
Frequency,
Active power,
Reactive power,
Apparent power,
Energy (Active/Reactive),
Power factor,

Features

¡¤Measurement accuracy class 0.5
¡¤Current measuring .../5 or .../1 A
¡¤1.6'¡¯ dot matrix LCD screen
¡¤Universal series power supply (85-265VAC/DC)
¡¤ITF Technology: galvanic insulation protection inputs outputs
¡¤Provide max 50 lists SOE record
¡¤Provide 5 virtual alarm trigger
¡¤Optional advanced electrical parameter*
¡¤Optional record and read multi- tariffs ratio, Up to 3 months
¡¤With RS-485 Modbus/RTU Communications
¡¤With 1 channel Pulse Output (PO) for active energy counting
¡¤Optional 4 channel Digital Input (DI) and 2 channel Digital Output (DO)
