DH1-20 Peltier Cooler Intelligent Enclosure Dehumidifier
Send Inquiry- Product Details
- Company Profile
The DH1-20 Intelligent Enclosure Dehumidifier (semiconductor dehumidifier) is a device used to control and maintain the environmental humidity inside the electrical cabinet. Its main function is to reduce the humidity level inside the electrical cabinet to ensure the normal operation and protection of electrical equipment. This Enclosure Dehumidifier is equipped with an intelligent control module, which uses a microcomputer processing chip with strong anti-interference. The double-row digital tubes display the measured value and the set value at the same time, and alternately display the current temperature and humidity, and realize the automatic control function of the humidity. Contact directly to get the dehumidifier for Enclosures or outdoor enclosures.
DH1-20 series Peltier condenser using semiconductor technology, in a certain place of cabinet to lead controlled condensation, make the interior environment humidity fall to safe value. It is refrigerant-free cooling device, can used in switchgear, electrical cabinet, exchange control cabinets, outdoor terminal boxes etc.
It designed ultra-small install size, high efficiency energy-saving, do not need extra heater and fan wiring. And comes with the data acquisition module for remote monitoring, It‘s an efficient and reliable device to replace the old thermostat and heater / fan combination.
Feature
Humidity Control: The intelligent enclosure dehumidifier can monitor the humidity level inside electrical cabinets and automatically adjust their operation to maintain a safe humidity range.
Energy Efficiency: The intelligent dehumidifier for enclosures is for energy efficiency, helping to reduce energy consumption & improve overall efficiency.
Alarm System: It typically comes with alarm systems that can alert you when humidity reaches dangerous levels, allowing you to take timely action.
Smart Control: Some units have smart control features, enabling integration with other systems for remote monitoring and control.
Ease of Maintenance: This enclosure dehumidifier is usually designed with easy installation and maintenance in mind.
Max power 20W, Built-in sensor, ABS shell, dehumidifying capacity 100ml/Day
Specification
| Data Name | Technical Data | |
| Working power | Power supply | 85V~265VAC/DC 50Hz |
| Peltier rated power(1) | 20W | |
| Air volume flow | 30m3/h | |
| Dehumidifying capacity | 100ml/Day @35°C,90%RH | |
| Measurement and ability | Humidity monitor range | 20%RH~98%RH |
| Sensor accuracy | ±5%RH | |
| Dehumidify start threshold | 45%RH~98%RH, Default 65%RH | |
| Environment temperature | 5~60°C | |
| Temperature monitor range | -40~80°C | |
| Sensor accuracy | ±1.0°C | |
| Heater start threshold | 1~55°C, Default 5°C | |
| Heater power | 50~500W optional | |
| Other | Physical dimension | 75*90*53mm |
| Screen | 1 digital LED | |
| Standards | IEC60255-22-1 | |
| Communication | RS485, Modbus-RTU (Optional) | |
| Notes: 1. The rated power is related to the cabinet’s inner volume and airtightness, and the general reference value is: 0.5cubic meter cabinet choose 15w 1.0cubic meter cabinet choose 30w 1.5cubic meter cabinet choose 40w 2.0cubic meter cabinet choose 60w Cabinet volume is calculated according to the physical dimension (Length*Width*Height).2. The DH1-20 intelligent enclosure dehumidifier is with a built-in external sensor. The sensor accuracy is 5%.3. The intelligent enclosure dehumidifier provides passive NO contact for external heater connection, capacity is AC250V5A. You can free to order heaters or purchase with the DN series. | ||
