Place of Origin: Jiangsu, China Brand Name: Bafang Model Number: g510 Battery Capacity: other Power Supply: Lithium Battery Wheel Size: 12", 14", 16", 18", 20", 22", 26", 28" Display: LCD, dpc-18 display Motor Type: Brushless Gear Hub Motor Battery Position: Down Tube Bike Throttle: Thumb Product name: Bafang G510 48V 1000W Bafang ultra G510 mid motor Kit Construction: Geared brushless mid motor Sensor: Speed sensor& torque sensor intergrated Throttle: thumb throttle Cranks: 170mm Max torque: 160N.m Chain wheel: 44T G.W.: 11kg

Product Introduction

The mid-drive motor constantly samples relevant information at a frequency of up to 80k Hz via a torque sensor and two speed sensors

which are all highly sensitive. The resulting data on crank torque, vehicle speed an the speed of rotation of the pedal is made available to

the controller, ensuring precise control of the vehicle while achieving the highest possible efficiency. The max drive system puts the rider

in complete control. In spite of a generous power output and a maximum torque of more than 160N.m, the motor operates in virtual silence.

The modular motor design and intergrated controller make disassembled by easier and improve service responsiveness.

Difference between mountain type motor and snow bike type motor is different shape of cranks and chain wheel

Packing List

Product Details Show

Customer Feedback

Why choose us

Company introduction

CNEBIKES Co., Ltd is located in Changzhou city ,Jiangsu ,China. We are just one hour from Shanghai

by high-speed train . It is easy for potential customers to come and have a look at our facility and products.
We manufacture a variety of products . Our products are reliable and durable. We export to Europe, the USA

, Canada, Southeast Asia, Australia and many other countries . Our customers have given us high praise for

our products and service.

Packing and shipping

1.Packing:
Standard export carton packing, with professional foam protection.
2.Shipping:
For samples, we deliver goods to customer by UPS,FEDEX,DHL,TNT or EMS.
For mass production order, we deliver goods to customer by air or by sea.

Warranty terms

motor--->2 years(guarantee replacement in first year, guarantee repair in the next year.)
battery---->1years(guarantee replacement.),
other parts---->half an year

Payment terms

We accept all kinds of payment term, e.g. bank T T, Western Union, Paypal etc.
After payment, please tell us your details address, zip code and phone NO. We will deliver goods for u ASAP.
