2/4/8/16 channel CWDM Mux/Demux Module
- Product Details
- Company Profile
Baudcom provide 2/4/8/16 channel CWDM Mux/Demux Module which are used for CWDM System,PON Networks,CATV Links
Features







From 1260nm to 1620nm

From -40 degree to 85degree


2. Applications
CWDM System
PON Networks
CATV Links
3. Compliance
Telcordia GR-1209-CORE-2001
Telcordia GR-1221-CORE-1999

RoHS
Specifications
CWDM Mux/Demux Module
Parameters | 1x2 | 1x4 | 1x8 | 1x16 | |
Center Wavelength (nm) | ITU, ITU+1 | ||||
ITU±6.5 | |||||
Operating Wavelength (nm) | 1460~1620 or 1260~1620 | ||||
Channel Space (nm) | 20 | ||||
Fiber Type | SMF-28e or customer specified | ||||
IL (dB) (P/A Grade) | 0.7/1.0 | 1.4/1.7 | 2.0/2.5 | 3.5/4.0 | |
Isolation (dB) | Adjacent Channel | 30 | |||
Non-Adjacent Channel | 50 | ||||
Ripple (dB) | 0.3 | 0.4 | 0.5 | 0.5 | |
PDL (dB) | 0.2 | ||||
PMD (ps) | 0.1 | ||||
RL (dB) | 45 | ||||
Directivity (dB) | 50 | ||||
Maximum Optical Power (mw) | 500 | ||||
Operating Temperature (℃) | -40~85 | ||||
Storage Temperature (℃) | -40~85 | ||||
BOX Package (mm) | 100*80*10 | 140*115*18 | |||
LGX Package | 1U, 2U | ||||
19’’ Rack mount Package | 1U |
Notes:
1. Specified without connectors.
2. Add an additional 0.2dB loss per connector.
