CKC6163
Chat Now!
Send Inquiry- Product Details
- Company Profile
This series machines are semi-circle controlled, with some advanced functions like threading tolerance compensation, variable frequency acceleration and so on. With this machine, not only the machining jobs which a horizontal lathe does can be done, but
SPECIFICATIONS
UNIT
MODEL
CKC/CKD6163，CKC/CKD6183，CKC/CKD6193
Center height
mm
315，415，465
Max swing over bed
mm
630，830，930
Max swing over carriage
mm
320，490，590
Max. part length
mm
750，1000，1500，2000，3000，4500
Max. turning length(saddle stoke)
mm
600，850，1350，1850，2850，4350
Spindle bore diameter
mm
φ105
Spindle bore taller
Metric120
Range of spindle speed
r/min
13-1000/10-800
Main motor power
Kw
11
Quill diameter
mm
φ90
Quill taper
MT5
Quill travel
mm
260
Quill travel of tailstock
mm
±15
rapid traverse
mm
X：4000 Z：8000
X travel
mm/min
380，530，530
Z travel
mm
600，850，1350，1850，2850，4350
Size of tool rot
mm×mm
32×32
Positioning accuracy
mm
X：0.03，Z：0.04，0.045，0.05
Repeatability
mm
X：0.012，Z：0.016，0.02，0.025
Roudness
mm
0.005，0.01
Flatness
mm
0.025/300
Surface roughness
um
Ra3.2
Standard CNC System
GSK980T/KND1000
Dimensions
Length
mm
2875，3155，3620，4135，5135，6635
Width
mm
1750，1950，1950
Height
mm
1700，1850，1950
Net weight
kg
3800，4000，4300，4600，5200，6500
